PROCESSOR
Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for Socket AM4
See supported processors
CHIPSET
AMD® X570 Chipset
MEMORY
• 4 DDR4 memory slots, support up to 128GB (depending on the processor)1
o 3rd Gen AMD Ryzen™ Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 Mhz by A-XMP OC MODE
o 2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 Mhz by A-XMP OC MODE
• Dual channel memory architecture
• Supports non-ECC UDIMM memory
• Sports ECC UDIMM memory (non-ECC mode)
• Supports un-buffered memory
1. Please refer to Compatibility for more information on compatible memory
See supported memory
SLOTS
• 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
o 3rd Gen AMD Ryzen™ support PCIe 4.0 x16 mode
o 2nd Gen AMD Ryzen™ support PCIe 3.0 x16 mode
o Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0 x8 mode
• 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E3, supports x4 mode)
• 3 x PCIe 3.0 x1 slots1
1. PCI_E2 will be unavailable when installing the PCIe card in PCI_E4 slot.
2. The speeds may vary for different devices
ONBOARD GRAPHICS
• 1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @24Hz1
1. Only support when using Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Processors
2. Maximum shared memory of 2048 MB
MULTI-GPU
• Supports 2-Way AMD® CrossFire™ Technology
STORAGE
AMD® X570 Chipset
• 4x SATA 6Gb/s ports(SATA3-SATA6)
• 2 x M.2 slot (Key M)
o M2_1 slot (from AMD® Processor)
Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics)
Supports 2242/ 2260/ 2280/ 22110 storage devices
o M2_2 slot (from AMD® X570 Chipset)
Supports PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
ASMedia ASM1061
• 2x SATA 6Gb/s ports (SATA1, SATA2)
RAID
AMD® X570 Chipset
• Supports RAID 0, RAID 1 and RAID 10
USB
AMD® X570 Chipset
• 6 x USB 3.2 Gen 1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.2 Gen 1 connectors)
• 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
AMD® Processor
• 2 x USB 3.2 Gen 2 (3rd Gen AMD Ryzen™) or USB 3.2 Gen1 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) ports (1x Type-A & 1x Type-C) on the back panel
• 2 x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
AUDIO
Realtek® ALC1220 Codec
• 7.1-Channel High Definition Audio
• Supports Optical S/PDIF output
LAN
• 1 x Realtek® 8111H Gigabit LAN Controller
INTERNAL CONNECTORS
• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x 4-pin ATX 12V power connector
• 6 x SATA 6Gb/s connectors
• 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 2 x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
• 1 x 4-pin CPU fan connector
• 1 x 4-pin water-pump connector
• 4 x 4-pin system fan connectors
• 1 x Front panel audio connector
• 2 x System panel connectors
• 1 x TPM module connector
• 1 x Serial port connector
• 1 x Clear CMOS jumper
• 1 x Chassis Intrusion connector
• 2 x 4-pin RGB LED connectors
• 2 x 3-pin RAINBOW LED connectors
• 4 x EZ Debug LEDs
BACK PANEL PORTS
1. Keyboard / Mouse
2. USB 3.2 Gen1 Type-A
3. LAN Port
4. HD Audio Connectors
5. Flash BIOS Button
6. USB 2.0 Ports
7. HDMI Port
8. USB 3.2 Gen2 Ports (Type-A + C)
9. USB 3.2 Gen1 Type-A Ports
10. Optical S/PDIF out
DIMENSIONS
• 12 in. x 9.6 in. (30.4 cm x 24.3 cm)
• ATX Form Factor
MOUNTING
9 mounting holes
OPERATING SYSTEM
• Support for Windows® 10 64-bit
